ASUS Prime Radeon RX 9070 OC Edition 16GB GDDR6

Specifications

• Model: PRIME-RX9070-O16G

• GPU Architecture: RDNA 4.0 (Navi 48)

• Graphics Processor: Navi 48

• Stream Processors: 3,584

• Base Clock: 1,660 MHz

• Game Clock:

  • Default Mode: Up to 2,120 MHz
  • OC Mode (GPU Tweak III): Up to 2,140 MHz

• Boost Clock:

  • Default Mode: Up to 2,590 MHz
  • OC Mode (GPU Tweak III): Up to 2,610 MHz

• Memory:

  • Type: GDDR6
  • Size: 16 GB
  • Bus Width: 256-bit
  • Memory Speed: 20 Gbps
  • Memory Bandwidth: 640 GB/s

• Display Outputs:

  • 1 × HDMI 2.1b
  • 3 × DisplayPort 2.1a

• Maximum Digital Resolution: 7680 x 4320

• Interface: PCIe 5.0 x16

• Dual BIOS: Yes (Performance/Quiet modes)

• Cooling:

  • Triple Axial-Tech Fans
  • 2.5-slot design
  • Dual Ball Fan Bearings

• Additional Features:

  • 0dB Technology (fans stop under 55°C)
  • Vented Backplate for enhanced heat dissipation
  • Auto-Extreme Technology for improved reliability

• Dimensions: 312 mm x 50 mm x 130 mm

• Power Connectors: 1 × 16-pin (12VHPWR)

• Recommended PSU: 750W or higher
