Specifications

• Platform: AMD
• Chipset: AMD B850
• Socket: AM5
• Form factor: Micro ATX
• Memory type: DDR5
• Maximum memory: 256GB
• M.2 slots: 2
• SATA ports: 4 (SATA 6Gb/s)
• Audio: Realtek High Definition Audio
• Features:
  • RAM Slots: 4 × DDR5 DIMM
  • Memory Architecture: Dual Channel
  • Memory Speed: Up to DDR5-8200 (OC)
  • Memory Profiles: AMD EXPO / Intel XMP
  • Wi-Fi: Wi-Fi 6E
  • Wireless Bands: 2.4GHz / 5GHz / 6GHz
  • Bluetooth: Bluetooth 5.3
  • CPU Support: AMD Ryzen 9000 / 8000 / 7000 Series
  • Primary Expansion Slot: 1 × PCIe x16
  • Primary PCIe Version: PCIe 5.0 x16 with Ryzen 9000 / 7000 Series
  • Secondary Expansion Slot: 1 × PCIe 3.0 x16 (x4 Mode)
  • Primary M.2: PCIe 5.0 x4/x2 with Ryzen 9000 / 7000 Series
  • Secondary M.2: PCIe 4.0 x4/x2
  • RAID Support: RAID 0 / 1 / 5 / 10 for NVMe, RAID 0 / 1 / 10 for SATA
  • LAN: Realtek 2.5GbE
  • Audio Channels: Up to 7.1 Channel
  • Display Outputs: 1 × HDMI 2.1 / 2 × DisplayPort 1.4
  • Maximum HDMI Resolution: 4096 × 2160 @ 60Hz
  • Maximum DisplayPort Resolution: 3840 × 2160 @ 144Hz
  • Multi-Display Support: Up to 3 Displays
  • Rear USB-C: 1 × USB 3.2 Gen 2 Type-C
  • Rear USB-A: 1 × USB 3.2 Gen 2 / 2 × USB 3.2 Gen 1 / 4 × USB 2.0
  • Front USB-C Header: USB 3.2 Gen 2
  • RGB Headers: 3 × Addressable RGB Gen2 / 1 × RGB
  • CPU Power Connector: 1 × 8-Pin ATX 12V
  • Main Power Connector: 1 × 24-Pin ATX
  • BIOS: 256Mbit AMI UEFI BIOS
  • Special Features: Q-Flash / Q-Flash Plus / GIGABYTE Control Center
  • Dimensions: 24.4 × 24.4 cm
  • SATA Ports: 4 × SATA 6Gb/s
